Premium Floating Dock Platform Sections
$1,245.98 – $1,657.73
Premium Floating Dock Sections are the best way to build your own custom floating dock. The 4x8ft Frames have superior float capacity and potential for limitless floating dock configurations.
Build your own custom floating dock with these Premium Floating Dock Sections. Each dock section is a 4x8ft floating frame with your choice of decking, and side stability floats. The kit assembles to a dock section that can be combined in countless configurations. Add a Premium Dock Section to a Premium Floating Dock package to enlarge the patio or dock length. Drop in decking panels nest into the frame, making installation an easy process. Multiple floating sections bolt together with 4″ bolts (not included with this kit).
FRAME:
- Weight per frame: 45 pounds
- Frame Height: 4 inches
- Frame Weight Capacity: 45 PSF when constructed as specified
- Frame Material: Aluminum (Marine Grade 6061-T6)
- Frame Style: Low Profile
- Frame Build: Bolts Together
- Hinge Span: Every 16 feet
FLOAT:
- Float Material: High-Density Polypropylene
- Foam-filled: Yes
- Float Dimensions: 48x24x12
- Float Capacity: 390 pounds
STABILITY FLOATS:
- Float Material: High-Density Polypropylene
- Foam-filled: No
- Float Dimensions: 47-1/4″ x 13-1/2″ x 6-3/4″
- Float Capacity: 145 pounds
DECKING:
- Decking Panel Measurements: 48x48x1 inches
- Cedar Panel Weight: 37 pounds
- Cedar Details: Unfinished Premium Western Red Cedar 48x6x1 inch Boards with Stringers
- Poly Panel Weight: 30 pounds
- Poly Details: Four 48x12x1 inch Polypropylene Panels with Aluminum Reinforcements and Stringers
- Aluminum Panel Weight: 25 pounds
- Aluminum Details: Premium 48x6x1 inch Extruded Aluminum Boards with Bolted Stringers, Powder Coating, and Wood Grain Finish
HINGE:
- Hinge Material: Aluminum
- Hinge Dimensions: 48×1 inches
- Hinge Articulation: 25 degrees
HARDWARE:
- Hardware material: Grade 8 Zinc-plated
- Hardware size: 3/8″ or 1/2″
- (1) 4×8 Floating Dock Frame
- (2) 4×4 Decking Panels
- (2) Floats w/ Hardware
- (4) Side Stability Floats
*Anchoring system and 4″ Bolt Kits not included
